HDD

• 64MB memory module supports RAID 1, 0
• Supports SAS and SATA disk drives
• Available upgrades: 128MB battery-backed write cache (BBWC) module

The HP ProLiant BL45p G2 supports two (2) optional, dual port fiber channel adapters for SAN connectivity and redundancy. Customers are offered a choice of either QLogic-based or Emulex-based fiber channel adapters. Both adapters are mezzanine circuit boards which connect directly to the server blade system board. These fiber channel adapters are available via option kits and must be ordered separately.

• QLogic-based
  • Utilizes a QLogic ISP2312 chipset
  • The HP QLogic-based dual port Fibre Channel Adapter (P/N  361426-B21) is compatible with the HP ProLiant BL20p G3, BL20p G4, BL25p G2, and BL45p G2 server blades. It cannot be used with HP ProLiant BL25p G1, BL35p, or BL45p G1 server blades
  • Includes two small form factor pluggable transceivers with LC connectors for installation into the Patch Panel 2, CGESM or GbE2 Interconnect Switch (with the Storage Connectivity Kit)
• Emulex-based
  • Utilizes an Emulex "Thor" chipset
  • The HP Emulex-based dual port fibre channel HBA (P/N  394757-B21) is compatible with the HP ProLiant BL20p G3, BL20p G4, BL25p G2, and BL45p G2 server blades. It cannot be used with HP ProLiant BL25p G1, BL35p, or BL45p G1 server blades
  • There are no SFP's included in the Emulex mezzanine kit for use with ProLiant BL p-Class Fibre Channel pass-through interconnects. If you require SFPs for use with an Emulex mezzanine and a FC pass through interconnect please order an SFP option kit (P/N  397577-B21) which will provide 2 FC SFPs per option kit
• Two ports on each Dual-port Fibre Channel Mezzanine Card provide a redundant Fibre Channel connection to each server blade
• Supports up to 2 Gb/s Fibre Channel equipment

HP ProLiant BL45p G2 server blades are optimized for StorageWorks MSA, EVA, and XP arrays.

HP ProLiant BL45p G2 server blades are compatible with select 3rd party SANs (please see blade storage page for more details):
http://h18000.www1.hp.com/products/servers/proliant-bl/p-class/storage.html

Starting July 9, 2007, HP Insight Control management suites and most HP ProLiant Essentials will include one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. From more information about this service, please visit: http://www.hp.com/services/insight.

Insight Control Environment for BladeSystem delivers foundation management for HP BladeSystem lifecycles, including hardware resource deployment, health monitoring, software version control, performance monitoring, vulnerability, scanning and patch management.
Installs and licenses the following components by default using a wizard-based integrated installer:

• HP Systems Insight Manager
• HP iLO Select Pack
• HP Insight Power Manager
• HP ProLiant Essentials Rapid Deployment Pack
• HP ProLiant Essentials Performance Management Pack
• HP ProLiant Essentials Vulnerability and Patch Management Pack
• HP ProLiant Essentials Virtual Machine Management Pack

Additional ProLiant Essentials software and management tools included on the Insight Control Management DVD can be installed manually.

• Server Migration Pack - Universal Pack
• HP Open Service Event Manager
• HP Instant Support Enterprise Edition

NOTE: Server Migration Pack - Universal Edition can be installed from the SMP-P2P CD included in the Insight Control Management media kit.
NOTE: Insight Control Environment for HP BladeSystem can be installed from the Insight Control Management DVD, which can be delivered with HP BladeSystem c-Class enclosures with a choice of licensing options. Licensing options include a free 30 day evaluation license for 8 servers (default option for every enclosure order), a full purchased license for 8 blade servers or a full purchased license for 16 blade servers). For additional information on HP c-Class Infrastructure please visit: HP BladeSystem c-Class Infrastructure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12517_na/12517_na.html
NOTE: For additional product and licensing information about Insight Control Environment for BladeSystem, HP Systems Insight Manager and Essentials software refer to http://www.hp.com/servers/proliantessentials.

HP Insight Control management suites and most HP ProLiant Essentials will include one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. From more information about this service, please visit: http://www.hp.com/services/insight.

Optional software offerings that selectively extend the functionality of an Adaptive Infrastructure to address specific business problems and needs:

• Insight Control Environment for BladeSystem is based on HP Systems Insight Manager and ProLiant Essentials software, and brings the value of Insight Control to ProLiant customers by delivering comprehensive health and performance monitoring, remote control, vulnerability scanning and patch management as well as flexible deployment and power management through an integrated installation package and streamlined licensing. For more information, visit: http://www.hp.com/go/ice

• Server Migration Pack - Universal Edition - Upgrading, replacing, or virtualizing your existing server? Effortlessly transition to new virtual or physical HP ProLiant servers or BladeSystem with automated, accurate and affordable migration of OS, application and data. SMP Universal automates the manual processes required for migrating servers between physical or virtual platforms, whether migrating to VMware or Microsoft virtual machines. SMP Universal allows all of the following:

  • Physical to ProLiant

  • Physical to virtual

  • Virtual to virtual

  • Virtual to ProLiant

• Virtual Machine Management Pack - Get the most out of server virtualization by unifying the management of physical and virtual servers in HP Systems Insight Manager. The Virtual Machine Management Pack plug-in provides central management and control of VMware and Microsoft virtual machines and provides physical host to virtual machine association.


NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product QuickSpecs for more information.

• Integrated Lights-Out Select Pack - upgrades the iLO 2 processor with enhanced console sharing and replay, virtual media (floppy, CD/DVD, USB key), virtual folders, historical power reporting, power capping and enterprise security (directory services and two-factor authentication) for servers managed using remote consoles available in iLO 2 Standard and iLO 2 Standard Blade Edition.

NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product QuickSpecs for more information.
NOTE: Selected software packages listed here include one year of 24 x 7 Software Technical Support and Update Service. If you have any questions about this service please visit the HP website at http://www.hp.com/services/insight

SmartStart is a tool that simplifies single server setup, providing a rapid way to deploy reliable and consistent server configurations. SmartStart can now deploy the ProLiant BL45p G2 server blades using the I/O port with an attached USB CD-ROM device. To obtain a copy of SmartStart for your blade server, redeem the coupon that is included with your Blade server or order your copy from the SmartStart web site. For more information, please visit the SmartStart Web site at http://www.hp.com/servers/smartstart.

SmartStart version supported (minimum): SmartStart 7.60

Windows Server 2003, Web edition
Windows Server 2003, Server/Standard edition (32 & 64 bit editions)
Windows Server 2003, Enterprise edition (32 & 64 bit editions)
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Solaris 10 (32 & 64 bit editions)
VMware ESX Server 3

NOTE: For a complete and up-to-date listing of supported OSs and versions, please visit our OS Support Matrix at: http://www.hp.com/go/supportos.
NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant BL p-Class, please see: http://h18004.www1.hp.com/support/files/server/us/family/model/5342.html.
NOTE: For a more complete and up-to-date information on Linux support, please visit HP Linux Web site at: http://h18000.www1.hp.com/products/servers/linux/hpLinuxcert.html.
NOTE: For more Linux OS support & certification information, please visit our the ProLiant & Bladesystem Server Linux matrix http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html

VMware Virtualization Software

Integrated Lights-Out 2 (iLO 2) Standard Blade Edition (integrated on motherboard)

• Virtual KVM based remote console
• Virtual Media (single server, browser based access only)
• Remote Serial Console
• Virtual Power Button Control
• Virtual Unit ID control
• Integrated Remote Console
• Dedicated network connectivity
• Embedded system health
• Browser, command line and scripted access
• Automatic IP Configuration via DHCP/DNS/WINS
• Industry Standard RC4, 128-bit Secure Sockets Layer (SSL) and Secure Shell (SSH) Security
• IML and iLO Event Logging
• Support for 12 user accounts with customizable access privilege
• Single sign-on from HP BladeSystem Onboard Administrator

• Dual Port Fibre Channel Mezzanine Card (optional) for redundant SAN connection
• Two hot-plug SAS/SATA hard drive bays and integrated RAID (Smart Array E200i) controller on every server blade (Battery-backed write cache is optional)
• Redundant ROM on every server blade
  Advanced ECC Memory support on every server blade - Advanced ECC can actually correct a multi-bit error (up to 4 bits) that occurs within one memory chip
• Redundant fan design on every server blade - The HP BL45p G2 server features ten (10) integrated fans for sufficient cooling. A single fan on each side of the server can fail without interrupting server operations indefinitely
• Network adapter teaming (network fault tolerance, transmit load balancing, switch-assisted load balancing)

• Power-on password
• Administrator's password One (1) internal USB 2.0 connector for security key devices and USB drive keys
• Integrated Lights-Out 2 has 12 customizable user accounts and SSL encryption
• Integrated Lights-Out 2 can be disabled via a Global Setting

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to http://www.hp.com/go/factory-express.

The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Additional support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements.

NOTE: Server Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support. Additional information regarding worldwide limited warranty and technical support is available at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
NOTE: Server Blade Limited Warranty includes 3 year Parts, 1 year Labor, 1-year on-site support. This warranty supports the HP ProLiant 35p Server Blades.
NOTE: Server Blade Enclosure Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support.
NOTE: Server Blade Interconnect Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support.
NOTE: The p-Class SAN switch limited warranty is unique to the SAN switch which includes 1 year warranty that is upgradeable to 3 years via Care Pack

HP services provide total care and support expertise with committed response designed to meet your IT and business needs.

The HP Care Pack services ProLiant BL p-Class server blades, cover the server blade and all HP branded hardware options qualified for the server, purchased at the same time or afterwards, internal to the server.

HP Care Pack services for HP BladeSystem p-Class server blade enclosure covers the enclosure including patch panels, HP supported Ethernet interconnects, power enclosure with power supplies and power distribution.

To fully capitalize on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vendor support solutions provides a range of support services designed to meet the varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Recommended Service - Simplify ProLiant solution implementation, maintenance and management.

• Support Service - 4-Hour Response Coverage, 3-Year, 24 x 7, Same Business Day

• Deployment Service - Installation and Start Up for HP BladeSystem Infrastructure


Enhanced Service - Optimize service level to increase IT performance and availability

• Support Service - HP Proactive BladeSystem Service, 1-Year

• Deployment Service - Enhanced Network Installation and Start-up for HP BladeSystem Switches


Installation & Start-Up service for HP BladeSystem Infrastructure plus HP BladeSystem Enhanced Network Installation and Start-UP as per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.

For a complete listing of service offerings and information visit:
http://www.hp.com/services/bladesystemservices
http://www.hp.com/go/proliant/carepack

HP ProLiant BL45p G2 2220, 2GB (2P)
438216-B21

HP BL45P G2 8218 4GB (2P)
408669-B21

HP BL45P G2 8216 4GB (2P)
408668-B21

HP BL45P G2 8214 4GB (2P)
408667-B21

Up to 4 HP BL45p G2 server blades plug vertically an HP BladeSystem p-Class server blade enclosure

NOTE: HP BladeSystem p-Class server blade enclosures with enhanced backplane components might be required depending on which HP ProLiant server blade model is selected. Please visit the enclosure compatibility matrix at http://www.hp.com/go/bladesystem/enclosure/compatibility.

Four embedded Gigabit Ethernet NIC ports:

• Two (2) embedded NC373i Multifunction Gigabit Network Adapters
• One (1) embedded NC324i Dual Port Gigabit Network Adapter

Plus (1) additional 10/100 NIC dedicated to iLO 2 management.

For dual (2) processor configurations choose (ONE of the following):

AMD Opteron processor Model 8218 (2.6GHz, 95W) Option Kit, FIO Base

AMD Opteron processor Model 8216 (2.4GHz, 95W) Option Kit, FIO Base

AMD Opteron processor Model 8214 (2.2GHz, 95W) Option Kit, FIO Base

AMD Opteron processor Model 8212 (2.0GHz, 95W) Option Kit, FIO Base

HP 10647 (47U) Rack Cabinet – Shock Pallet

245160-B23

HP Rack 10622 (22U) Cabinet – Crated

245163-B23

Following are memory options available from HP:

HP 1GB REG PC2-5300 2x512MB 1RANK Kit

HP 2GB REG PC2-5300 2x1GB 1RANK Kit

408851-B21

HP 4GB REG PC2-5300 2x2GB 2RANK Kit

408853-B21

HP 8GB REG PC2-5300 2x4GB 2RANK Kit

408854-B21

To review typical system power ratings use the Active Answers Power Calculator which is available via the online tool located at URL: http://www.hp.com/go/bladesystem/powercalculator

Blackplane connection
